COLUTEA 500
520CLT.4-I1175
Wall-mounted fixture with 360º light emission, radial beam.
Cylindrical design with a diameter of 140mm.
Luminaire height: 300mm.
Protection rating against dust and moisture: IP66 – full protection.
Protection rating for resistance against harmful mechanical impacts: IK10.
Die-cast aluminium body and top cover made of die-cast aluminium coated with polyester powder along with C4 treatment for corrosion resistance to guarantee further durability. Textured paint finish. Different RAL colour finishes available under request. C5-M special coating for highly corrosive environments is available under request.
7mm opal borosilicate glass.
Aluminium disks to get specific photometric results and to increase visual comfort.
A4 stainless steel locking screw. Optional supply of A2 stainless steel vandal-resistant screw.
Silicone gasket.
Anticondensation device.
PCB on the top of the fixture.
Built-in driver included. Ambient temperature: up to 50ºC.
Electronic options for light control: DALI.
Pre-wiring with 25cm of 3x1mm2 cable.
Double cable gland entry for installation in series.
IP68 connector not included, it can be ordered separately: F3.A3 (On/Off) / F3.A5 (DALI).
Mounting to the wall through mounting plate with two fixing holes. Cable entry from the mounting plate.
Luminous flux of the light source: 1529lm
Luminous flux of the luminaire: 183lm
Luminaire efficiency: 18 lm/W
Light source power: 10 W
Luminaire power: 10 W
mA: 500 mA
Colour temperature: 1795K
Chromaticity Tolerance: MacAdam 4
CRI: 55
Beam angle: 360
Photobiological safety group: 1
This product contains a light source of energy efficiency class: consult
Rated Median useful life: 52000h L80B50
Class: 1
IP: 66
IK: IK10
Incandescent filament: 850°Luminaire diameter: 140
Weight: 3.85 Kg
Electronic Equipment:
S: On/Off
D: DALI-2
There are accessories available for dimming devices.
*Add the suffix after the reference to indicate your electronic equipment choice.
